My Web

Welcome to the source code for my website! Please contact me if you would like to collaborate and thank you for visiting.

This website is self-hosted on my Raspberry Pi. Any interference or hax and the killswitch will activate and stop the UK national grid power system so please don't tamper with my domain :).

The use of AI

This has been created with a heavy amount of AI. Initially, I began with articles from medium informing me of how to use Nginx to host static sites and reverse proxy to other services. They were incredible helpful and I wish I were able to give credit them, but sadly they were read too long ago.

After hearing all the hype on LinkedIn and feeling the pressure to keep up a high output without AI, I eventually caved in. There is an immense advantage not having to scan though documentation to find relevant functions, asking how other developers implement their infrastructure and finding what command will achieve your outcome quickly. Sure, it would be good to have that already cached in your own human memory. But my reasoning is that you will have cached it after being reminded by AI enough times, similar to how flashcards work. I may not be an expert in the specific tool, though I've been able to get good enough at it for my own purposes.

Architecture

All services run in Docker containers orchestrated by Docker Compose behind Nginx as a reverse proxy on a single bridge network.

vue              ── Frontend build (outputs dist to shared volume)
nginx (80, 443)  ── Frontend SPA + Reverse Proxy
backend (8080)   ── Go API (GraphQL + REST)
db (5432)        ── PostgreSQL 16
icecast2 (8000)  ── Audio Streaming (Icecast2 + Liquidsoap)
gitea (3000)     ── Self-Hosted Git
quartz (8080)    ── Obsidian Notes Publisher (Quartz v4.4.0)
searxng (8080)   ── Meta Search Engine
hasura (8080)    ── Hasura GraphQL Engine (Docker profile: hasura)
autoheal         ── Auto-restart unhealthy containers
certbot          ── SSL Certificate Management (disabled in dev)

Tech Stack

Frontend - Vue 3, Vite, Tailwind CSS v4, Pinia, Vue Router, markdown-it (wikilinks + KaTeX), Rust/WASM

Backend - Go (Gin), gqlgen (GraphQL), GORM, PostgreSQL, JWT auth, WebSockets

Integrations - Spotify API, Steam API, Anthropic Claude API, Icecast2

Infrastructure - Docker Compose, Nginx, Let's Encrypt (Certbot), Gitea + Act Runner

Features

• Spotify integration (currently playing, recently played)
• Steam integration (online status, recent games)
• Obsidian note viewer via Quartz
• Live radio streaming via Icecast2 + Liquidsoap
• Real-time chat over WebSockets with image/video uploads
• Blog with admin panel (CRUD)
• Activity and rowing session tracking
• AI image processing integration to extract rowing data from images (will be superseeded by openCV scanning)
• Fan shrines (GTO, Evangelion, Demoman, Skip Skip Benben)
• Self-hosted Git (Gitea) with CI/CD and commit feed on homepage
• Printable CV with role-specific sections
• Job application tracker with status workflow and CSV export (admin-only, /cv/jobs)
• Database-backed bookmarks grouped by category, managed via GraphQL (admin-only)
• SearXNG meta search engine (admin-only)
• Hasura GraphQL console (admin-only)
• Admin-gated routes: /searxng, /notes, /hasura require admin JWT via Nginx auth_request
• Landing page with animated stamps section
• Route transitions (slide/fade) and performance optimizations (gzip, WOFF2 fonts, lazy loading)
• Backend healthcheck with autoheal container for automatic recovery

Pages

Route	Description
/	Landing page
/stp	Home dashboard with grid layout
/admin	Admin login + panel (authenticated)
/cv	Curriculum Vitae (printable)
/cv/jobs	Job application tracker (admin-only, hidden print)
/bookmarks	Bookmarks (database-backed, grouped by category)
/notes/:path	Obsidian note viewer (via Quartz, admin-only)
/shrines	Fan shrine index + individual shrines

API

GraphQL

Endpoint: POST /api/graphql Playground: GET /api/graphql (when GQL_PLAYGROUND=true)

Operation	Type	Description
users	Query	Get all users
user(id)	Query	Get user by ID
me	Query	Get authenticated user
posts	Query	Get all posts
post(id)	Query	Get post by ID
activities	Query	Get all activities
favorites	Query	Get all favorites
rowingSessions	Query	Get all rowing sessions
post(id)	Query	Get post by ID
activities	Query	Get all activities
favorites	Query	Get all favorites
rowingSessions	Query	Get all rowing sessions
messages	Query	Get all messages
spotifyListening	Query	Currently playing track
spotifyRecent	Query	Recently played tracks
giteaFeed	Query	Latest Gitea activity
steamStatus	Query	Steam online status
login	Mutation	Authenticate user
logout	Mutation	Logout
refreshToken	Mutation	Refresh auth token
createPost / updatePost / deletePost	Mutation	Post CRUD (admin)
createUser / deleteUser	Mutation	User management (admin)
setUserAdmin	Mutation	Toggle admin status
createFavorite	Mutation	Add favorite (admin)
createActivity	Mutation	Add activity (admin)
bookmarks	Query	Get all bookmarks
createBookmark / deleteBookmark	Mutation	Bookmark CRUD (admin)
jobApplications	Query	Get all job applications (admin)
createJobApplication / updateJobApplication / deleteJobApplication	Mutation	Job application CRUD (admin)

REST Endpoints

Auth

Method	Path	Description
POST	/api/auth/login	Login (rate limited: 5/min)
POST	/api/auth/refresh	Refresh token
GET	/api/auth/check	Check token validity
POST	/api/auth/logout	Logout
GET	/api/auth/validate-admin	Validate admin JWT (used by Nginx auth_request)

Access tokens are valid for 7 days; refresh tokens for 365 days. ValidateAdmin also refreshes the access token if it is within 24 hours of expiry.

Spotify

Method	Path	Description
GET	/api/spotify/callback	OAuth callback
GET	/api/spotify/listening	Currently playing
GET	/api/spotify/recent	Recently played

Public

Method	Path	Description
GET	/api/favorites	Get all favorites
GET	/api/rowing	Get all rowing sessions
GET	/api/activity	Get all activities
GET	/api/posts	Get all posts
GET	/api/posts/:id	Get post by ID
GET	/api/user	Get all users
GET	/api/user/:id	Get user by ID

Protected (auth required)

Method	Path	Description
POST	/api/messages/upload	Upload message file (rate limited: 5/min)

Admin (auth + admin required)

Method	Path	Description
POST	/api/favorites	Create favorite
POST	/api/rowing	Create rowing session
POST	/api/activity	Create activity
POST	/api/posts	Create post
PUT	/api/posts/:id	Update post
DELETE	/api/posts/:id	Delete post
POST	/api/user	Create user
PUT	/api/user/:id	Update user
DELETE	/api/user/:id	Delete user
PATCH	/api/user/:id/admin	Set/unset admin
POST	/api/radio/upload	Upload radio song
GET	/api/radio/songs	List radio songs
DELETE	/api/radio/songs/:filename	Delete radio song
PATCH	/api/radio/songs/:filename/disable	Disable radio song
PATCH	/api/radio/songs/:filename/enable	Enable radio song

WebSocket

Method	Path	Description
GET	/api/ws	WebSocket chat (10s ping keepalive)

Nginx Proxy Routes

Route	Target	Notes
/api	backend:8080	API (rate limited: 30r/s)
/radio	icecast:8000	Audio streaming
/gitea	gitea:3000	Git service
/hasura	hasura:8080	GraphQL console + WebSocket (admin-only)
/notes	quartz:8080	Obsidian notes (admin-only)
/searxng	searxng:8080	Search engine (admin-only)
/uploads	local alias	User-uploaded files

/hasura, /notes, and /searxng are protected by auth_request to GET /api/auth/validate-admin. Requests without a valid admin JWT are rejected with 401.

Deprecated Endpoints

Backend note API (GET /api/notes/*path) - The backend has a REST endpoint that serves note files directly from the mounted Obsidian vault. This is superseded by the Quartz service which now handles note rendering at /notes/. The backend endpoint still exists in code but is no longer the primary note serving path.

Setup

.env

Create a .env file in the project root. All services read from this file.

Variable	Description
POSTGRES_USER	PostgreSQL username
POSTGRES_PASSWORD	PostgreSQL password
POSTGRES_DB	Main app database name
POSTGRES_PORT	PostgreSQL port (typically 5432)
POSTGRES_HOST	PostgreSQL hostname (use db for Docker)
GITEA_HOST	Gitea hostname (use gitea for Docker)
GITEA_PORT	Gitea HTTP port (typically 3000)
GITEA_INTERNAL_TOKEN	Gitea internal API token (generate with gitea generate secret INTERNAL_TOKEN)
GITEA_LFS_JWT_SECRET	Gitea LFS JWT secret (generate with gitea generate secret LFS_JWT_SECRET)
GITEA_OAUTH2_JWT_SECRET	Gitea OAuth2 JWT secret (generate with gitea generate secret JWT_SECRET)
POSTGRES_GITEA_DB	Gitea database name
UPTIMEKUMA_HOST	Uptime Kuma hostname (planned)
UPTIMEKUMA_PORT	Uptime Kuma port (planned)
SEARXNG_HOST	SearXNG hostname (use searxng for Docker)
SEARXNG_PORT	SearXNG port (typically 8080)
SEARXNG_SECRET_KEY	SearXNG secret key (random hex string)
WALLABAG_HOST	Wallabag hostname (planned)
WALLABAG_PORT	Wallabag port (planned)
QUARTZ_HOST	Quartz hostname (use quartz for Docker)
QUARTZ_PORT	Quartz port (typically 8080)
GITEA_RUNNER_HOST	Gitea runner hostname
GITEA_RUNNER_NAME	Gitea runner display name
GITEA_RUNNER_REGISTRATION_TOKEN	Token to register Gitea Actions runner
BACKEND_PORT	Backend port (typically 8080)
BACKEND_HOST	Backend hostname (use backend for Docker)
BACKEND_SECRET	JWT signing secret
BACKEND_ENDPOINT	API path prefix (typically /api)
OBSIDIAN_DIR	Absolute path to Obsidian vault on host machine
SPOTIFY_CLIENT_ID	Spotify app client ID
SPOTIFY_CLIENT_SECRET	Spotify app client secret
SPOTIFY_REDIRECT_URI	Spotify OAuth redirect (e.g. https://www.<DOMAIN>/api/spotify/callback)
SPOTIFY_AUTH_STATE	Arbitrary state string for Spotify OAuth
ICECAST_SOURCE_PASSWORD	Icecast source connection password
ICECAST_RELAY_PASSWORD	Icecast relay password
ICECAST_ADMIN_USER	Icecast admin username
ICECAST_ADMIN_PASSWORD	Icecast admin password
ICECAST_HOST	Icecast hostname (use icecast for Docker)
ICECAST_PORT	Icecast port (typically 8000)
ICECAST_MOUNT	Icecast mount point (e.g. /stream)
LIQUIDSOAP_HARBOR_MOUNT	Liquidsoap live input mount (e.g. /live)
LIQUIDSOAP_HARBOR_PORT	Liquidsoap harbor port (e.g. 8005)
DOMAIN	Production domain name
EMAIL	Email for Let's Encrypt registration
CLAUDE_API_KEY	Anthropic Claude API key
STEAM_API_KEY	Steam Web API key
STEAM_ID	Steam user ID
HASURA_GRAPHQL_ADMIN_SECRET	Hasura admin secret
HASURA_HOST	Hasura hostname (use hasura for Docker)
HASURA_PORT	Hasura port (typically 8080)
SEED_DB	Set to true to seed test data on startup

Gitea Config

Copy from the template and fill in secrets:

cp gitea/config/app.ini.template gitea/config/app.ini

Populate LFS_JWT_SECRET, SECRET_KEY, INTERNAL_TOKEN, JWT_SECRET, and the database PASSWD. Alternatively, the Gitea entrypoint generates app.ini from the template using environment variables.

SearXNG Config

Copy from the template:

cp searxng/settings.yml.template searxng/settings.yml

The Docker entrypoint handles environment variable substitution (${BASE_URL}, ${SEARXNG_SECRET_KEY}) automatically, so manual setup is only needed when running outside Docker.

Spotify Token Setup

4. After authorization, Spotify redirects to the callback endpoint which stores tokens at /backend/token/spotify_token.json
5. Tokens are refreshed automatically; the file persists across container restarts via volume mount

Obsidian Notes Setup

1. Set OBSIDIAN_DIR in .env to the absolute path of your Obsidian vault on the host machine
2. The vault is mounted read-only into the Quartz container at /quartz/content
3. Quartz builds a static site from the vault on startup and serves it at /notes/
4. The backend also mounts the vault at /backend/notes (legacy, see deprecated endpoints above)

SSL Certificates (Certbot)

Initial setup (production):

1. Set DOMAIN and EMAIL in .env
2. On first run, Nginx starts with nginx_setup.conf.template which only serves the ACME challenge route at /.well-known/acme-challenge/
3. Certbot requests a certificate via certbot certonly --webroot
4. Once the certificate is issued to certbot/conf/live/<DOMAIN>/, restart Nginx — it will detect the certs and switch to the full nginx.conf.template
5. Certbot checks for renewal every 12 hours automatically

Dev mode: Nginx generates a self-signed certificate for localhost automatically.

Icecast Radio

Place at least one .mp3 file in icecast2/fallback_music/. Liquidsoap plays these as fallback when no live source is connected. Connect a live source to port 8001 on the LIQUIDSOAP_HARBOR_MOUNT.

Gitea Runner

1. Download the act_runner binary from Gitea releases and place in gitea-runner/
2. Set GITEA_RUNNER_REGISTRATION_TOKEN in .env
3. The runner registers automatically on first startup

Dev Mode

Run the full stack over plain HTTP without SSL certificates:

docker compose -f docker-compose.yml -f docker-compose.dev.yml up --build

This:

• Uses an HTTP-only Nginx config with all routing (SPA, backend proxy, radio, gitea, etc.)
• Generates a self-signed certificate for localhost
• Disables certbot
• Seeds the database with test data (SEED_DB=true)
• Enables GraphQL playground and introspection
• Enables Hasura console and dev mode

Visit http://localhost to test.

Frontend only (hot reload)

cd vue && npm run dev

Vite dev server proxies /api to localhost:8080, /gitea to localhost:3000, /radio to localhost:8000.

Untracked Files

These files are git-ignored and must be created manually:

File	Notes
.env	See setup section above
gitea/config/app.ini	Copy from app.ini.template or let entrypoint generate it
searxng/settings.yml	Copy from settings.yml.template or let entrypoint generate it
certbot/conf/, certbot/www/	Created automatically by certbot; use dev mode to skip
backend/token/	Created automatically by Docker volume mount
icecast2/fallback_music/*.mp3	Place at least one MP3 file
gitea-runner/act_runner	Download from Gitea releases
gitea-runner/.runner	Generated on first runner startup

Future Ideas

• More Rust to WASM
• ML for chatboards
• Cache requests
• Design more webpages
• Calendar to show radio times
• Nice smooth function background and transitions
• Design shrines
• Redis (not really but practical experience)
